TippingPoint 10/110/330 Hardware Installation and Safety Guide 15
Technical Specifications
The following section details the hardware and software specification for the TippingPoint 10.
• ”Hardware Specifications” on page 15
• ”Software Specifications” on page 15
Hardware Specifications
This section details the specifications for the hardware components.
Software Specifications
To run the TippingPoint Intrusion Prevention System (IPS), you must use one of the following:
• A network-connected PC that supports Internet Explorer 7.x or higher or Mozilla Firefox 3.x or higher.
• TippingPoint Security Management System (SMS) Software, Version 3.6 and above.
ACTIVE In the middle of each port pair that
comprises a segment.
Green: The unit is passing and
inspecting traffic.
No Light: The unit has no power or
is using the internal ZPHA to pass
traffic without inspection.
Power button On the Power button on the back of
the device.
Off: No power is coming from the
AC/DC adapter.
Red: The unit is standing by to start.
Press the power button again to
start the unit.
Blue: The unit is running.
Table 3-1 TippingPoint 10 LEDs
LED Location Description
Table 3-2 TippingPoint 10 Specifications
Feature Description
Dimensions 10.63 in x 7.32 in x 2.01 in
(27.0 cm x 18.6 cm x 5.1 cm)
Weight 5.1 lbs (2.3 kg)
Temperature Requirements 0 to 40 ° C (32 to104 ° F) — Operating
-25 to 70° C (-13 to 158 ° F) — Storage
Note: Please allow time for the device to return to room
temperature before powering the device on.
Humidity Requirements 5% to 95% (non-condensing)
Power Specifications Power Adapter: 110-240 VAC universal, 50-60 Hz, 5A
Power Output: 12 V DC
Maximum Data Rate 20 Mbps aggregate throughput between both segments
Rate Limits: Kbps 50, 100, 150, 200, 250, 300, 350, 400, 450, 500, 600,
700, 800, 900
Rate Limits: Mbps 1, 1.5, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 20
