30 Connector and Pinout Specifications

Use the following pinout information when your RJ-45 device is operating in 1000Mbps (1GbE) mode.

NOTE: These ports can auto-negotiate their mode and can automatically detect whether they should

operate in straight-through or cross-over mode.

7Ground (GND)

8Ground (GND)

Table A-3 RJ-45 Connector Pinouts

Pin Number Signal Name

1 Twisted Pair 1 positive (TP1+)

2 Twisted Pair 1 negative (TP1-)

3 Twisted Pair 2 positive (TP2+)

4 Twisted Pair 3 positive (TP3+)

5 Twisted Pair 3 negative (TP3-)

6 Twisted Pair 2 negative (TP2-)

7 Twisted Pair 4 positive (TP4+)

8 Twisted Pair 4 negative (TP4-)

Table A-2 RJ-45 Ethernet Connector Pinouts

Pin Number Signal Name
