User Guide B–1
B
Technical Specifications
✎
All performance specifications are provided by the component
manufacturers. Performance specifications represent the highest
specification of all HP’s component manufacturers’ typical level
specifications for performance and actual performance may vary
either higher or lower.
1506 Flat Panel Monitor
Display
Type
15.0 inches
TFT LCD
38.1 cm
Viewable Image Size 15.0-inch diagonal 38.1 cm
Tilt --5 to 30
o
Maximum Weight
(Unpacked)
7.0 lbs. 3.20 kg (unpacked)
Dimensions (include pedestal)
Height
Depth
Width
14.0 inches
8.0 inches
13.4 inches
355 mm
203 mm
340 mm
Maximum Graphic Resolution 1024 x 768 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.297 (H) x 0.297 (W) mm
Horizontal Frequency 30 to 63 kHz
