Technical Specifications
User Guide B–5
1906 Flat Panel Monitor
Display
Type
19.0 inches
TFT LCD
48.3 cm
Viewable Image Size 19.0-inch diagonal 48.3 cm
Tilt --5 to 30
o
Maximum Weight
(Unpacked)
11.7 lbs. 5.30 kg (unpacked)
Dimensions (includes pedestal)
Height
Depth
Width
16.8 inches
8.0 inches
16.6 inches
427 mm
203 mm
422 mm
Maximum Graphic Resolution 1280 x 1024 (60Hz)
Text Mode 720 x 400
Dot Pitch 0.294 (H) x 0.294 (W) mm
Horizontal Frequency 30 to 83 kHz
Vertical Refresh Rate 50 to 76Hz
Environmental Requirements
Temperature:
Operating Temperature
Non-operating Temperature
41 to 95
o
F
--4 to 140
o
F
5 to 35
o
C
--20 to +60
o
C
Relative Humidity 20 to 80%
Power Source 100 –- 240 VAC, 50 – 60 Hz
Altitude:
Operating
Non-operating
0 to 12,000 feet
0 to 40,000 feet
0 to 3657.6 m
0 to12192 m
