HP xw4600 Quickspecs

Security Features
Padlock support Padlock loop in rear of chassis. Locks side cover and secures chassis from theft. (0.22" diameter)
Cable Lock Support Kensington lock slot in rear of chassis. Locks side cover and secures chassis from theft. (3mm x
7mm opening)
Universal chassis clamp
lock support
Threaded feature in rear of chassis. Locks side cover and locks cables to chassis. Secures
chassis from theft and allows multiple units to be chained together when used with optional cable.
Solenoid lock and hood
sensor
Yes
Rear Port Control Cover
(optional)
Locks rear IO cables to prevent cable theft.
Serial, Parallel, USB
Enable/Disable
Enable or disable serial, parallel or USB ports and hide them form the operating system
Removable Media Write/
Boot Control
Prevents the computer from being booted from removable media on supported devices (and can
disable writes to media)
Power-On Password Prevents an unauthorized person from booting up the computer
Setup Password Prevents an unauthorized person from changing the system configuration
Other Features
ACPI-Ready Hardware Advanced Configuration and Power Management Interface (ACPI).
Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards and
peripherals in a low-power or powered-off state without affecting other elements of the
system
Insight Diagnostics HP Insight Diagnostics Offline Edition
The diagnostics utility enables you to perform testing and to view critical computer hardware and
software configuration information from various sources. This utility enables you to:
Run diagnostics
View the hardware configuration of the system
Key features and benefits
HP Insight Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating
the hardware issues. In addition to robust management tools, service tools can be invaluable in
quickly resolving system problems. To streamline the service process and resolve problems
quickly, it is necessary to have the right information available at the time that a service call is
placed. The primary information requirement, which is also the one that provides the greatest
insight into potential system issues, is the configuration of the system. Insight Diagnostics helps
provide higher system availability. Typical uses of the Insight Diagnostics are:
Testing and diagnosing apparent hardware failures
Documenting system configurations for upgrade planning, standardization, inventory
tracking, disaster recovery, and maintenance
Sending configuration information to another location for more in-depth analysis
QuickSpecs
HP xw4600 Workstation
Technical Specifications
DA - 12792 Worldwide QuickSpecs — Version 19 — 9.12.2008 Page 21

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
