High Definition
Integrated Realtek
ALC262 Audio
Type
Integrated
High Definition Codec
Yes
SPDIF
No
External audio jacks
One front stereo analog microphone-in
One front stereo headphone-out
One rear line-in
One rear line-out
One rear stereo analog microphone-in
Internal audio
connectors
AUX-IN line-level analog input
Retasking
NOTE:
Rear audio port are re-taskable as Line-In, Line-Out,
Microphone-In, or Headphone-Out with Optional driver, available only
through download from HP support website and not supported by
default. External Speakers need to be powered externally.
Sampling
44.1kHz/48 kHz/96kHz/192kHz (output only)
Wavetable Syntheses
(software)
Yes - Uses OS soft wavetable
Internal audio speaker
power rating
1.5 W
Internal Speaker
Yes
Microphone features
Stereo Microphone supporting:
Acoustic echo cancellation
Noise suppression
Beam forming
HP Thin USB Powered
Speakers
(KK912AA)
On/Off/Volume
Controls
Right side of right speaker
Power LED
Front of right speaker (green)
Frequency response
FO to 20kHz
Watts
2/3 watt (normal/maximum)
Dimensions
(H x W x D)
Speakers: 5.72 x 3.74 x 0.96 in (14.52 x 9.50 x 2.45 cm) per speaker
Net weight
0.68 lbs (0.31kg)
Environmental
(all conditions
non-condensing)
Temperature
(operating)
14° to 104° F (-10° to 40° C)
Relative Humidity
(operating)
40% to 90%
Speaker cable length
Input cord: 5.91 ft (1800mm±35mm)
L-channel cord: 3.28 ft (1000mm±35mm)
USB cord: 5.91 ft (1800mm±35mm)
Color
HP Carbonite
Option kit contents
One pair of HP Thin USB Powered Speakers with attached audio
signal and USB power cables for connecting to your PC
HP Warranty documentation
Sound Blaster X-Fi
XtremeMusic (PCI)
Audio Quality
Total Harmonic Distortion + Noise at 1kHz (20kHz Low-pass filter) =
0.004%
QuickSpecs
HP xw4600 Workstation
Technical Specifications - Audio
DA - 12792 Worldwide QuickSpecs — Version 19 — 9.12.2008
Page 27
