LSI SAS3041E Serial
Attach SCSI (SAS) Host
Bus Adapter
(HBA)
(Part# EH417AA)
PCI Bus
PCI-Express x4 lanes
PCI Modes
Bus Master DMA
PCI data burst transfer
rate
1.0 GBps ( half duplex ) 2.0 GBps ( full duplex )
SAS Bandwidths
Half Duplex
Single lane – 300 MBps
Wide Port (2 lanes) – 600 MBps
Wide Port (4 lanes) – 1200 MBps
Full Duplex
Single SAS Lane – 600 MBps
Wide Port (2 lanes) –1200 MBps
Wide Port (4 lanes) – 2400 MBps
PCI Card Type
3.3 volt add-in card
PCI Voltage
12 V ± 10%
PCI Form Factor
6.6" x 2.731" (Low-profile)
PCI Power
7.5 Watts
Bracket
Full height and Low-profile
Certification Level
PCI-Express 1.0a
IO Bus
Four 3Gbps SAS/SATA ports
SAS Processor
LSISAS1064E
Internal Connectors
Four- SATA x1 connectors
External Connectors
None
Integrated RAID Levels
RAID 0, 1, 1E, and 10E
Max. Number of
Physical Devices
122
LED Indicators
On-board activity and fault LEDs
Integrated Mirroring
Integrated Mirroring option available
Environments
Operating
Storage
Temperature
32° to 140° F (0° to 60° C)
-49° to 221° F (-45° to +105° C)
Relative Humidity
5% to 90% non-condensing 5% to 90% non-condensing
MTBF
>200,000 hours
Compliances
EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-
3/02.04); Europe (EN55022/EN55024); Australia/New Zealand (AS/NZS
3548); Safety: EN60950
Operating system
support
Microsoft Vista Business 32 and 64, Microsoft Windows XP
Professional, Microsoft Windows XP Professional x64,Red Hat
Enterprise Linux WS 4 and 5
Kit contents
Controller card, driver CD, LED cables, user documentation and
warranty card.
QuickSpecs
HP xw4600 Workstation
Technical Specifications - Controllers
DA - 12792 Worldwide QuickSpecs — Version 19 — 9.12.2008
Page 33
