HP xw4600 Quickspecs

1-3 Hard Disk Drives –
Up to 3 of the following
SATA drives, or 3 of the
following SAS drives
Windows Vista
i
Windows XP Red Hat Linux
SATA Hard Drives
80 GB 7200 rpm SATA 3.0 Gb/s NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
160 GB 7200 rpm SATA 3.0 Gb/s NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
250 GB 7200 rpm SATA 3.0Gb/s NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
500 GB 7200 rpm SATA 3.0Gb/s NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
1 TB 7200 rpm SATA 3.0 Gb/s NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
80 GB 10K rpm SATA NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
160 GB 10K rpm SATA NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
Serial Attached SCSI (SAS) Hard Drives (SAS controller required)
73 GB 15K rpm SAS 3.0 Gb/s 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
146 GB 15K rpm SAS 3.0 Gb/s 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
300 GB 15K rpm SAS 3.0 Gb/s 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
4th Hard Disk Drive –
One of the following (not
supported with 2nd
optical drive)
Windows Vista
i
Windows XP Red Hat Linux
SATA 3.0 Gb/s Hard Drives
160 GB 7200 rpm SATA 3.0 Gb/s NCQ drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
1 TB 7200 rpm SATA 3.0 Gb/s NCQ 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
Serial Attached SCSI (SAS) Drives (SAS controller required)
300 GB 15K rpm SAS 3.0 Gb/s drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
146 GB 15K rpm SAS 3.0 Gb/s 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
300 GB 15K rpm SAS 3.0 Gb/s 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
Factory Integrated
RAID
(on motherboard for
SATA drives)
All drives must be
identical in type and
capacity
All RAID arrays must be
less than 2 TB
Windows Vista
i
Windows XP Red Hat Linux
RAID 0 Configuration - Striped Array (SATA
or SAS)
32-Bit, 64-Bit 32-Bit, 64-Bit Not supported
RAID 0 Data Configuration - 32-Bit, 64-Bit 32-Bit, 64-Bit Not supported
RAID 1 Configuration - Mirrored Array (SATA
or SAS, 2 drive max.)
32-Bit, 64-Bit 32-Bit, 64-Bit Not supported
NOTE: Requires identical hard drives (speeds, capacity, interface. Specific user-configured
hardware SAS RAID configurations are supported on this Linux system. Please visit:
http://www.hp.com/support/linux_hardware_matrix for details.
Drive controllers Windows Vista
i
Windows XP Red Hat Linux
Integrated 6-channel SATA 3.0 Gb/s
controller with RAID * 0, 1, 5, 10 and NCQ
32-Bit, 64-Bit 32-Bit, 64-Bit Not Supported
Optional 4-port SAS LSI 3041E 3.0 Gb/s
RAID * Card **
32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
(RAID 0, 1)
* Specific user-configured hardware SAS RAID configurations are supported on this Linux system.
Please visit: http://www.hp.com/support/linux_hardware_matrix for details.
** Not supported when HD drive 1 is SATA
QuickSpecs
HP xw4600 Workstation
Standard Features - Specs
DA - 12792 Worldwide QuickSpecs — Version 19 — 9.12.2008 Page 4

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
