Miscellaneous

Windows Vista

Windows XP

Red Hat Linux

Solenoid lock and hood sensor

32-Bit, 64-Bit 32-Bit, 64-Bit

WS 4 & 5

Configure minitower in desktop orientation

32-Bit, 64-Bit 32-Bit, 64-Bit

WS 4 & 5

HP IEEE 1394a 3-Port PCI Card

32-Bit, 64-Bit 32-Bit, 64-Bit

Not Supported

Software

Windows Vista

Windows XP

Red Hat Linux

Standard

Alert Standard Format specification

32-Bit, 64-Bit 32-Bit, 64-Bit

N/A

HP Performance Tuning Framework

32-Bit, 64-Bit 32-Bit, 64-Bit

N/A

HP Backup and Recovery

32-Bit, 64-Bit 32-Bit, 64-Bit

N/A

PDF Complete

32-Bit, 64-Bit 32-Bit, 64-Bit

N/A

Optional

PDF Complete

32-Bit

32-Bit, 64-Bit

N/A

Optional

Microsoft Office 2007 Small Business Edition

32-Bit

32-Bit, 64-Bit

N/A

HP ProtectTools Security

32-Bit

32-Bit, 64-Bit

N/A

Form Factor

Minitower

Color

Carbonite/Alloy metallic

Convertibility

Yes. 5.25" drives rotate for Minitower or Desktop orientation.

Expansion Slots

(see

system board section for

more details)

3 PCI slots (full-height, full-length)

1 PCI Express x8 slot (x4 functionality)

1 PCI Express x1 slot (half length)

2 PCI Express x16 Gen2 slots (one dedicated for graphics)

Expansion Bays

(see

storage section for more

details)

2 internal 3.5" bays

1 external 3.5" bay, 3 external 5.25" bays*

NOTE:

Third external 5.25" bay is not full depth in side orientation.

Front I/O

2 USB 2.0, 1 IEEE 1394 (requires optional PCI card to function), 1 audio out, and 1 microphone.

NOTE:

Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and

an IEEE 1394 card, HP cannot provide customer support for this configuration. Please refer to the

Linux Hardware Support Matrix (

http://www.hp.com/support/linux_hardware_matrix

) for details, and

to the Linux User Manual (

http://www.hp.com/support/linux_user_manual

) for tips on user-

enablement of the IEEE 1394 Card.

Internal I/O

1 USB 2.0 Type A Receptacle, 2 USB 2.0 headers

Rear I/O

7 USB 2.0, 1 serial, 1 optional serial port, parallel port, 2 PS/2, RJ-45 (NIC), 1 External SATA, 1

audio line in, 1 audio line out, 1 microphone in; audio ports can be retasked to function as line in,

line out, microphone, or headphone.

Interfaces Supported

1 SATA 3 Gb/s interface (5 internal, 1 external SATA connectors)

On-board RAID Support

SATA

(Specific user-configured hardware SAS RAID configurations are supported on this Linux

system. Please visit:

http://www.hp.com/support/linux_hardware_matrix

for details.)

Chassis Dimensions

(W x D x H)

Standard minitower orientation: 6.6 x 17.9 x 17.7 inches; 16.8 x 45.6 x 45.0 cm

Converted desktop orientation: 17.7 x 17.9 x 6.6 inches; 16.8 x 45.0 x 45.6 cm

Weight

Exact weights depend upon configuration

Minimum: 29.9 lbs (13.6 kg)

Standard: 33.3 lbs (15.1 kg)

Maximum: 43.3 lbs (19.6 kg)

QuickSpecs

HP xw4600 Workstation

Standard Features - Specs

DA - 12792 Worldwide QuickSpecs — Version 19 — 9.12.2008

Page 7
