HP Z1 G2 Product End-Of-Life Disassembly Instructions

h)remove power cable from MB
i) remove MB
18) Remove CPU bracket/CPU
a) Pull the latch lever and open the
bracket
b) Take the CPU away from socket
c) remove PCIe card
d) remove back plate
19)Remove memory
a) Pull the latch spring and
disassemble the Dimm
20)remove spring
EL-MF877-00 Page 11
Template Revision B
PSG instructions for this template are available at EL-MF877-01
