HP Z1 Specification

System Board
System Board Form Factor Custom Motherboard, Custom Rear IO board, Custom Side IO board
Processor Socket Single LGA 1155
CPU Bus Speed DMI
Chipset Intel® PCH C206
Super I/O Controller Nuvoton NPCD379H
Memory Expansion Slots 4 DDR3 memory slots
Memory Type Supported 2GB, 4GB, and 8GB ECC Unbuffered DIMMs;
2GB non-ECC Unbuffered DIMMs
Mixing of ECC and non-ECC DIMMs is not supported.
Memory Speed Supported Up to 1600MHz DDR3
Maximum Memory 32GB ECC or 8GB non-ECC
PCI Express Connectors 1 MXM slot (PCIe Gen2 x16, DP x 2)
3 miniPCIe slots (PCIe Gen2 x1, USB 2.0)
Supported Drive
Interfaces
SATA Integrated Serial ATA interfaces (2x 6Gb/s SATA, 1x 3Gb/s
SATA).
NOTE: the Z1 supports a maximum of two SATA SFF/SSD drives
only. RAID 0 and 1 supported. (Factory integrated RAID is
Microsoft Windows only).
Integrated RAID NOTE: Requires identical hard drives (speeds, capacity,
interface)
Integrated Graphics Integrated Intel HD Graphics 2000 (on Intel Core i3
processors).
Integrated Intel HD Graphics P3000 (on Intel Xeon E3-
12x5 processors).
Unified Memory Architecture (UMA)- A region of system
memory is reserved and dedicated to the graphics
display.
DirectX 10.0 compliant.
OpenGL 3.0 on Intel HD Graphics P3000)
Integrated graphics can support dual display across the
embedded DP to the LCD panel and the DP output on the
Rear IO.
Network Controller Integrated Gbit LAN MAC by Intel PHY Lewisville 82579LM;
Management capabilities WOL, PXE 2.1 and AMT 7
IEEE 1394 Connector(s) Side 1 IEEE 1394a
USB Connector(s) Side 2 USB 3.0
Rear 4 USB 2.0
Internal 1 USB 2.0 Type A, 2 USB 2.0 on a 9-pin header
HD Integrated Audio Intel HD / IDT 92HD91 codec
Flash ROM Yes
CPU Fan Header Yes
QuickSpecs
HP Z1 Workstation
System Technical Specifications
DA - 14263 North America — Version 21 — October 4, 2013 Page 14

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
