HP Z1 Specification

Integrated Intel HD
Graphics Media
Accelerators
Form Factor Integrated
Graphics Controller Intel Integrated Graphics Media Accelerator HD
Memory Unified Memory Architecture (UMA) frame buffer. Graphics memory is shared
with system memory. Size selectable between 64 MB to 512 MB via BIOS
setting. Default size is 64 MB. Additional memory is allocated for graphics as
needed using Intel's Dynamic Video Memory Technology (Intel DVMT 5.0), to
provide an optimal balance between graphics and system memory use.
Connectors 1 Embedded DisplayPort to LCD panel, 1 DisplayPort on rear IO
Graphics adapters are orderable as an accessory as necessary.
Maximum Resolution Display Port: 2560 x 1600
RAMDAC Integrated, 350 MHz
Display Output Integrated dual independent monitor support facilitated via one embedded DP
and one DisplayPort integrated on the rear IO. VGA support via optional
DisplyPort to VGA adapter.
Supported Graphics APIs Intel HD Graphics 2000: Microsoft DirectX 10, OpenGL 2.1
Intel HD Graphics P3000: Microsoft DirectX 10.1, OpenGL 3.0
NVIDIA Quadro 500M 1GB
Graphics
Form Factor MXM v3.0 Type A (82mm x 70mm)
Graphics Controller N12M-Q3, 560MHz core clock
Bus Type PCI Express x16 (part of MXM v3.0 connector)
Memory 1GB DDR3, 128 bit wide interface, 800MHz
Connectors One MXM v3.0 connector (285-pin)
Maximum Resolution 2 x 2560x1600 @ 60Hz digital displays
In Z1 application:
- Internal Display: 2560x1440
- External Display via DP connector: 2560x1600
RAMDAC Not Applicable
Image Quality Features Capable of 10-bit per channel (3 channels) internal display processing,
including hardware support for 10-bit per channel scan-out
64-bit texture filtering and blending
Advanced vertex and pixel shaders, antialiasing, 16x anisotropic filtering
MPEG-2 HD and WMV HD video playback (1920x1080p)
H.264 hardware decode acceleration
AES-128 CTR/CBC/ECB decryption modes supported
Advanced video algorithms
NVIDIA Digital Vibrance Control 3.0
Shading Architecture Shader Model 5.0 support
96 processor cores
Supported Graphics APIs Full IEEE 764-2008 32-bit or 64-bit precision
DirectX 11.0 Shader Model 5.0
OpenGL 4.0
Compute API support for NVIDIA CUDA C, CUDA C++, DirectCompute 5.0,
OpenCL, Java, Python and Fortran
QuickSpecs
HP Z1 Workstation
Technical Specifications - Graphics
DA - 14263 North America — Version 21 — October 4, 2013 Page 32

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
