HP Z1 Specification

NOTE 4 : For detailed OS/hardware support information for Linux, see:
http://www.hp.com/support/linux_hardware_matrix .
Available Processors
Name Cores
Clock
Speed
(GHz)
Intel® Turbo
Boost
Technology
1
Cache
(MB)
Memory
Speed
(MHz)
Hyper-
Threading
Featuring
Intel® vPro™
Tech-nology
Intel® HD
Graphics
TDP
(W)
Intel® Xeon®
processor
E3-1280v2
4 3.6 4.0 8 1600 Y Y N/A 69W
Intel® Xeon®
processor
E3-1245v2
4 3.4 3.8 8 1600 Y Y
Intel HD
Graphics
P4000
77W
Intel® Xeon®
processor
E3-1225v2
4 3.2 3.6 8 1600 N Y
Intel HD
Graphics
P4000
77W
Intel® Core™ i5-
3470 processor
4 3.2 3.6 6 1600 N Y
Intel HD
Graphics
2500
77W
Intel® Core™ i3-
3220 processor
2 3.3 N/A 3 1600 N N
Intel HD
Graphics
2500
55W
1The specifications shown in this column represent the maximum frequency (GHz) of one processor core when accelerated with Intel
Turbo Boost Technology. Turbo boost stepping occurs in 100MHz increments. Processors that do not have turbo functionality are
denoted as N/A.
Available Processor
Disclaimers
Intel Xeon E3 and Intel Core i3 processors can support either ECC or non-ECC memory.
Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families. See:
http://www.intel.com/products/processor_number/ for details.
64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See: http://www.intel.com/info/em64t for more
information.
Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers
or software applications will necessarily benefit from use of these technologies.
Integrated Display See below for detailed information
Panel
Type: IPS (in-plane switching) LED Backlit LCD
Viewable Image Area: 68.5 cm, (27 in.) widescreen; diagonally measured
Screen Opening (W x H): 59.8 x 33.6 cm, (23.5 x 13.3 in.)
Optimal Resolution: 2560 x 1440 @ 60 Hz; 3.7MP
Aspect Ratio: 16:9 Widescreen
Viewing Angle (typical): Up to 178° horizontal/178° vertical (10:1 minimum contrast ratio)
QuickSpecs
HP Z1 Workstation
Overview
DA - 14263 North America — Version 21 — October 4, 2013 Page 5

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
