HP Z210 Support Manual

Product Items/Features
(Blank box or unlisted means the component is NOT supported)
RH EL DT 5.4 or later (x86
& x86
_
64
)
RH EL WS 6.0 or later (x86
& x86
_
64
)
SLED11 or later (x86_64)
HP Workstation Base Syste
m
Base system includes: Chassis, System Board, USB, Power Supply, etc.
•••
Localization Kit (See footnote 1)
HP Localization Kit
•••
Software
Remote Graphics Software
All Supported Processors
All Supported Processors (1 CPU configs) •••
Hyperthreading
•••
Graphics Card (Video Card) (See footnote 2)
No Graphics Card
•••
Intel Onboard Graphics Vesa Driver Only Intel Driver Only Intel Driver Only
NVIDIA Quadro NVS 295
•••
NVIDIA Quadro NVS 300
•••
NVIDIA Quadro FX380 LP (Low Profile)
•••
NVIDIA Quadro Q600
•••
ATI v3800 PCI-E - Single Card Supported
•••
System RAM
Minimum (GB)
1GB 1GB 1GB
Maximum (GB)
16GB 16GB 16GB
Hard Disks
All Supported SAS disk drives
All Supported SSD disk drives •••
All Supported SATA disk drives •••
All Supported USB Drive Keys •••
Network Cards (no modem support)
Intel Pro 1000 CT Gigabit PCI
•••
Broadcom 5761 PCI-Express
•••
Onboard Components
Onboard LAN - Intel 82578DM Gigabit Ethernet
•••
Onboard Audio
•••
Onboard SATA RAID
444
Add Ons
IEEE 1394A PCI Card
•
SATA Controllers
555
Creative Sound Blaster X-Fi
•••
Removable CD/DVD Media
HP 16x DVD-ROM Drive
•••
HP 16x Super Multi DVD+RW
333
HP BD-RE (writer)
•••
Input/Output Devices (no spaceball support)
HP 3-Button Mouse, PS/2
•••
HP Scroll Mouse, PS/2
•••
HP Optical Scroll Mouse, USB
•••
HP Standard Keyboard, USB/PS2
•••
TPM module/ Smart Card
22 in 1 Card Reader
•••
HP Printers
666
All supported monitors
•••
footnote 5 - The Z200 SFF can support up to 2 SATA drives.
footnote 6 - For more info about Linux driver support for HP Printers please visit http://www.hplip.net.
footnote 7 - Hyperthreading is supported on all platforms when the processor allows it.
Hardware Support Matrix for Current HP Linux Workstations
HP Z200 SFF Workstation Linux Support
First time support begins with RHEL5.4 (x86 & x86_64), RHEL6.0 (x86 & x86_64) and SLED 11 (x86_64)
footnote 1 - Localization supported: (ABA US English, ABC French Canadian, ABD Germany, ABE Spain, ABF France, ABG Australia, ABU UK English, ABJ Japan, AB2 China (PRC)
AB4 Singapore/ Malaysia, ABZ Italy, AB5 Hong Kong, ACF Japan-English, ACJ India-English, AB0 Taiwan, AK6 Europe A4, AC0 Belgium, ABS Sweden, ABB Int'l English).
footnote 2 - Get the latest drivers, "HP Installer Kit for Linux - HP Driver CD for Red Hat Enterprise Linux 5.4", and "HP Installer Kit for Linux - HP Driver CD for SuSE Linux Enterprise
Desktop 11" ISO images from http://www.hp.com/support/z200 (substitute correct platform name); Select "download drivers and software".
footnote 3 - Linux growisofs supports DVD+RW and Blu-ray media on Red Hat EL 5 Desktop or later and SLED11 or later. For drives that have the Lightscribe functionality, please visit
www.lightscribe.com for software to enable the labeling feature.
footnote 4 - Hardware RAID is not supported on SATA drives.

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
