HP Z210 Support Manual

Product Items/Features (Blank box or unlisted
means the component is NOT supported)
RH EL WS 4.6 or later (x86 &
EM64T
)
RH EL DT 5.1 or later (x86 &
x86_64
)
SLED11 or later (x86_64)
hp workstation base system
Base system includes: Chassis, System Board, USB, Power Supply, etc.
•••
Localization Kit (See footnote 1)
HP localization kit
•••
Software
Remote Graphics Software
All Supported Processors
All Supported Processors (1 & 2 CPU configs) •••
Hyperthreading
Graphics Card (Video Card) (See footnote 3)
No Graphics Card
•••
NVIDIA Quadro NVS 290
•••
NVIDIA Quadro NVS 295
•••
NVIDIA Quadro NVS440
•••
NVIDIA Quadro NVS450
•••
NVIDIA Quadro FX370
•••
NVIDIA Quadro FX380
•••
NVIDIA Quadro FX570
•••
NVIDIA Quadro FX580
•••
NVIDIA Quadro FX1700
•••
NVIDIA Quadro FX1800
•••
NVIDIA Quadro FX3700
•••
NVIDIA Quadro FX3800
•••
NVIDIA Quadro FX4600
•••
NVIDIA Quadro FX4800
•••
NVIDIA Quadro FX5800
•••
SLI Graphics Connector
ATI v5600 PCI-E
ATI v5700 PCI-E
ATI v7700 PCI-E
ATI v7750 PCI-E
System RAM
Minimum (MB)
512 512 512
Maximum
128GB 128GB 128GB
Hard Disks
All Supported SAS disk drives 666
All Supported SATA disk drives 666
All Supported USB Drive Keys •••
Network Cards (no modem support)
Broadcom 5751 PCI-Express
•••
Intel Pro 1000 PT Gigabit PCI
•••
Onboard Components
Onboard LAN - Broadcom 5755 10/100/1000
•••
Onboard Audio
•••
Onboard SATA/SAS RAID
555
Add Ons
IEEE 1394 PCI Card
Creative Sound Blaster X-Fi
LSI 8888 ELP
555
Hardware RAID
555
Removable CD/DVD Media
HP 48x CD-ROM Drive
•••
HP 16x DVD-ROM Drive
•••
HP 48x DVD/CDRW Combo
•••
HP 16x dual-layer DVD+RW
444
Input/Output Devices (no spaceball support)
HP 3-Button Mouse, PS/2
777
HP Scroll Mouse, PS/2
777
HP Optical Scroll Mouse, USB
777
HP Standard Keyboard, USB
777
Modular keyboard/ TPM module/ Smart card
HP Printers
888
All supported monitors
•••
footnote 8 - For more info about Linux driver support for HP Printers please visit http://www.hplip.net
footnote 2 - Not orderable integrated into systems. Order AMO (After Market Only) kit.
footnote 1 - Localization supported: (ABA US English, ABC French Canadian, ABD Germany, ABE Spain, ABF France, ABG Australia, ABU UK English, ABJ Japan, AB2 China(PRC), AB4
Singapore/ Malaysia, ABZ Italy, AB5 Hong Kong, ACF Japan-English, ACJ India-English.
HP xw8600 Workstation Red Hat Linux Support
First time support begins with RHEL4.5 (x86 & x86_64), RHEL5 (x86 & x86_64), and SLED 11 (x86_64)
footnote 7 - Keyboard/Mouse interface must be either PS2 or USB; mixing is not supported.
footnote 6 - Mixed hard drives are not offered on the preload. Use SATA or SAS, not both. We do offer mixed drives on the HPIKL (FreeDos) configuration.
Hardware Support Matrix for Current HP Linux Workstations
footnote 4 - Linux growisofs supports DVD+RW on Red Hat EL WS 3 or later. For drives that have the Lightscribe functionality, the labeling functionality is not supported.
footnote 3 - Get the latest drivers, "HP Installer Kit for Linux - HP Driver CD for Red Hat Enterprise Linux 4.6", and "HP Installer Kit for Linux - HP Driver CD for Red Hat Enterprise Linux 5.1" ISO
images from http://www.hp.com/support/xw8600 (substitute correct platform name); Select "download drivers and software".
footnote 5 - Hardware RAID is supported using the LSI 8888 ELP (RAID 0,1, 5 SAS Only) and Onboard SAS RAID (RAID 0,1,). SATA RAID is not supported.

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
