HP Z220 SFF Specification

1
The specifications shown in this column represent the maximum turbo frequency with one core active. Turbo boost stepping occurs in
100MHz increments. Processors that do not have turbo functionality are denoted as N/A.
Available Processor
Disclaimers
Integrated Intel® HD graphics is not supported on the Intel® Xeon E3-1230v2, E3-1240v2, E3-1270v2 or
E3-1280v2 Processors.
Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.
Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families. See:
http://www.intel.com/products/processor_number/ for details.
64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See: http://www.intel.com/info/em64t for more
information.
Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers
or software applications will necessarily benefit from use of these technologies.
Color Jack Black
Convertibility The Z220 SFF can either be placed flat on the desktop or made to stand on the desk with the optional
tower stand.
Expansion Slots (see
system board section for
more details)
1 PCIe Gen3 x16 slot
1 PCIe Gen2 x4 slot /x16 connector
1 PCIe Gen2 x1 slot
1 PCI
(all slots are Low Profile)
NOTE: In the PCIe Gen3 x16 slot, if it is not being used for a graphics card, only cards certified as After
Market Options for this platform are supported.
Expansion Bays (see
storage section for more
details)
1 internal 3.5" bay, and 1 shared internal/external 3.5" bay.
1 external 5.25" bay.
Front I/O 4 USB 2.0, 1 Headphone, and 1 Microphone
Internal I/O 4 USB 2.0 ports available by two separate 9-pin headers
Rear I/O 1 VGA and 1 DisplayPort (DP 1.1)output from Intel HD graphics (available on specific processors only); 4
USB 3.0 ports, 2 USB 2.0 ports, 1 standard and 1 optional serial port, 1 optional parallel port, 2 PS/2, RJ-45
(NIC), 1 Audio Line-in, and 1 Audio Line-out; 2 IEEE 1394b ports(optional).
Interfaces Supported 22-in-1 Media Card Reader (optional)
Chassis Dimensions
(H x W x D)
Standard desktop orientation: 100 x 338 x 381 mm (3.95 x 13.3 x 15.0 in);
Optional SFF Tower orientation (excluding stand dimension): 338 x 100 x 381 mm (13.3 x 3.95 x 15.0 in)
Weight Exact weights depend upon configuration;
Typical Weight * 7.5 kg (16.5 lbs)
Shipping Weight * 8.1 kg (17.86 lbs)
Max Supported Weight (desktop orientation) 35 kg (77 lb)
*Configured with 1 3.5" hard drive, 1 optical drive, 2 DIMMs and 1 NVIDIA NVS 300 graphics card
Temperature Operating: 40° to 95°F (5° to 35°C)
Non-operating: -40° to 140°F (-40° to 60°C)
QuickSpecs
HP Z220 SFF Workstation
Overview
DA - 14265 North America — Version 21 — November 21, 2013 Page 4

HP Z220 SFF Specifications

General

Bus type	DMI
Stepping	E1
FSB Parity	No
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor codename	Ivy Bridge
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Thermal Design Power (TDP)	77 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	32
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HDA
Product type	Workstation
Motherboard chipset	Intel® C216
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	Quadro 600
Power supply type	AC
Power requirements	100 - 240V, 50/60Hz
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	Intel, NVIDIA
Maximum storage capacity	4 TB
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Number of displays supported (on-board graphics)	3
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Parallel ports quantity	-
Chassis type	SFF
Product color	Black
Country of origin	China
Operating system installed	Windows 7 Professional
Power supply	240 W
Processor ARK ID	65733
Intel TSX-NI version	0.00
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	- g
