HP Z24i G2 User Manual

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size ( if
applicable)
Description #1 Screw driver of "+" type
Description #2 Hexagonal nut screw driver for DVI and D-SUB connector
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove the Stand-base
2. Remove the Rear cover
3. Remove the pin and the screw
4. Remove the the tapes and the pins.
5. Remove the screws
6. Remove the Mylar
7. Remove the mainboard and powerboard
8. Remove the The mainframe
9. Remove the keyboard &bezel & panel
10.
11.
12.
13.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment ( with descriptions and arrows identifying locations) .

HP Z24i G2 Specifications

General

3D	No
HD type	WUXGA
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LED
Native aspect ratio	16:10
Vertical scan range	30 - 94 Hz
Horizontal scan range	60 - 75 kHz
Viewable size, vertical	324 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518.4 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
On/off switch	Yes
Pivot angle	0 - 90 °
Tilt angle range	-5 - 22 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Annual energy consumption	36 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	2
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black
Country of origin	China
Market positioning	Business

Weight and Dimensions

Depth (with stand)	205 mm
Width (with stand)	538.8 mm
Height (with stand)	463 mm
Weight (with stand)	6600 g
Depth (without stand)	46.8 mm
Width (without stand)	532 mm
Height (without stand)	351 mm
Weight (without stand)	3700 g
