HP Z27n G2 User Manual

1
10. Mechanical Instructions
Step Figure Description
Remove the
HINGE ASS'Y
Press the button
to remove the
hinge assy
Remove the
REAR_COVER
Remove the
screws first,and
remove the rear
cover ,then
remove the key
board from rear
cover

HP Z27n G2 Specifications

General

3D	No
Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	24 - 75 Hz
Horizontal scan range	27 - 112 kHz
Viewable size, vertical	335.6 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Pivot angle	0 - 90 °
Tilt angle range	-5 - 22 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
USB upstream port type	USB Type-C
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
Product color	Silver
Country of origin	China
Market positioning	Business
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Annual energy consumption	62 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	45 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	214 mm
Height (with stand)	509 mm
Weight (with stand)	11000 g
Depth (without stand)	47.1 mm
Width (without stand)	613 mm
Height (without stand)	364 mm
Weight (without stand)	8000 g
