HP Z420 Specification

Integrated Trusted
Platform Module
Integrated TPM 1.2
Power Supply Headers Yes
Power Switch, Power LED
& Hard Drive LED Header
Yes
Clear Password Jumper Yes
Serial Port 1 internal header
Parallel Port No
Keyboard/Mouse USB or PS/2
Power Supply
Power Supply 600W 90% Efficient, Custom PSU
(Wide Ranging, Active PFC)
Operating Voltage Range 90–269 VAC
Rated Voltage Range 100–240 V 118 V
Rated Line Frequency 50–60 Hz 400 Hz
Operating Line Frequency Range 47–66 Hz 393-407 Hz
Rated Input Current 100–240 V @ 8.0 A 118 V @ 8.0 A
Heat Dissipation Typical: 1365btu/hr (344 kg-cal/hr)
Maximum: 2354btu/hr (593 kg-cal/hr)
Power Supply Fan 92x25 mm variable speed
ENERGY STAR Qualified
(Configuration dependent)
Yes
80 PLUS® Compliant 90% Efficient
The Z420 600W power supply efficiency report can be found at this link:
http://www.plugloadsolutions.com/psu_reports/HEWLETT
PACKARD_623193-001_ECOS 2619 1_600W_Report.pdf
FEMP Standby Power Compliant @115V (Wake-on
LAN disabled) (<2W in S5 - Power Off)
Yes
EuP Compliant @ 230V
(<1 W in S5 - Power Off)
Yes
CECP Compliant @ 220V
(<4W in S3 - Suspend to RAM)
Yes; Configuration dependent
Power Consumption in sleep mode (as defined by
ENERGY STAR) - Suspend to RAM (S3) (Instantly
Available PC) measured at 115V.
<10W
Built-in Self Test LED Yes
Surge Tolerant Full Ranging Power Supply
(withstands power surges up to 2000V)
Yes
QuickSpecs
HP Z420 Workstation
System Technical Specifications
DA - 14261 North America — Version 33 — December 12, 2013 Page 18

HP Z420 Specifications

General

Tcase	64 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1603
System bus rate	0 GT/s
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.8 GHz
Processor cache type	L3
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	28
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	31.4 GB/s
Maximum internal memory supported by processor	375 GB
Product type	Workstation
Motherboard chipset	-
Internal memory	4 GB
Memory channels	Quad-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Discrete graphics card model	AMD FirePro V4900
Maximum graphics card memory	1.024 GB
Graphics card family	AMD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Operating system installed	Windows 7 Ultimate
Sustainability certificates	ENERGY STAR
Processor code	SR0L9
Processor ARK ID	64600
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX

Weight and Dimensions

Depth	- mm
Weight	- g
