Page #41 background imageLoading...
Page #41 background image
LSI 9212 4-Port SAS 6Gb/s
RAID Card
PCI Bus
8-lane, 5GT/s PCI Express 2.0
PCI Modes
Bus Master DMA
RAID Levels
RAID 0, 1, 1E and 10
PCI Data Burst Transfer
Rate
Half Duplex, x4 PCIe 2000 MB/s
Full Duplex, x8 PCIe 4000 MB/s
SAS Bandwidth
Half Duplex
Single lane - 600 MB/s
Wide Port (2 lanes) - 1200 MB/s
Wide Port (4 lanes) - 2400 MB/s
Full Duplex
Single SAS Lane - 1200 MB/s
Wide Port (2 lanes) -2400 MB/s
Wide Port (4 lanes) - 4800 MB/s
PCI Card Type
3.3V Add-in card
PCI Voltage
12 V ± 10%
PCI Power
13.5 Watts
Bracket
Full height and Low-profile
Certification Level
PCI-Express 2.0
IO Bus
1x4 6Gb/s SAS ports
SAS Processor
LSISAS2008
Internal Connectors
Four x1 SATA
External Connectors
None
Maximum Number of SCSI
Devices
256
LED Indicators
Internal
Activity/Fault per x4 port - Heartbeat
LSI 9217-4i4e 8-port SAS
6Gb/s RAID Card
PCI Bus
8 lanes, PCI Express 3.0
RAID Levels
Offers Integrated RAID (0, 1, 1E and 10)
PCI Data Burst Transfer
Rate
Half Duplex x8, PCIe, 8000 MB/s
SAS Bandwidth
Half Duplex
600 MB/s per lane
PCI Card Type
3.3V Add-in card
PCI Voltage
12 V ± 10%
PCI Power
9.8W typical, Airflow min 200 LFM
Bracket
Full height and low profile
Certification Level
PCI Express 3.0 compliant
IO Bus
1x4 6Gb/s SAS ports
SAS Processor
LSI SAS2308/ Fusion MPT 2.0
Internal Connectors
One x4 internal mini-SAS (SFF8087)
External Connectors
One x4 external mini-SAS (SFF8088)
QuickSpecs
HP Z420 Workstation
Technical Specifications - Hard Drive Controllers
DA - 14261 North America — Version 33 — December 12, 2013
Page 41
