HP Z420 Specification

Memory Size: 512MB DDR3
Clock: 875Mhz
Memory Bandwidth: 14GB/s
Connectors 2 x DisplayPort
Maximum Resolution Up to 2560 x 1600 (digital display) per display.
Image Quality Features The following video formats are supported:
- MPEG2
- MPEG4 Part 2 Advanced Simple Profile
- H.264 SVC codec support
- Support for 3D Blu Ray
- VC1
- DivX version 3.11 and later
- MVC
A full range of video resolutions are supported including 1080p, 1080i, 720p,
480p and 480i. The NVS 310 GPU provides hardware acceleration for the
computationally intensive parts of video processing, as well as provides
improved video playback speeds via faster decode and transcode.
Display Output Up to 2 displays in the following configurations:
DisplayPort output:
Drives two DisplayPort enabled digital display at resolutions up to 2560
× 1600 at 60 Hz with reduced blanking, when connected natively using
the 2 DisplayPort connectors on the NVS 310 graphics card
Supports 2 monitors up to resolution of 1920 × 1200 at 60 Hz with
reduced blanking using DisplayPort 1.2 multi stream topology
technology.
DVI-D output:
Drives two digital display at resolutions up to 1920 × 1200 at 60 Hz with
reduced blanking using DisplayPort to DVI-D single-link cable adaptors
Drives two digital display at resolutions up to 2560× 1600 at 60 Hz with
reduced blanking using DisplayPort to DVI-D dual-link cable adaptors
HDMI output:
NVS 310 is capable of driving two high definition (HD) panels up to
resolutions of 1920 × 1080P at 60 Hz using DisplayPort to HDMI cable
adaptors
VGA display output:
Drives two analog display at resolutions up to 1920 × 1200 at 60 Hz
using DisplayPort to VGA cable adaptors
Shading Architecture Shader Model 5.0
Supported Graphics APIs DX11, OpenGL 4.1
Available Graphics
Drivers
Windows 8
Genuine Windows 7 Professional (64-bit and 32-bit)
QuickSpecs
HP Z420 Workstation
Technical Specifications - Graphics
DA - 14261 North America — Version 33 — December 12, 2013 Page 44

HP Z420 Specifications

General

Tcase	64 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Processor cache	10 MB
Processor cores	4
Processor model	E5-1603
System bus rate	0 GT/s
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.8 GHz
Processor cache type	L3
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	28
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	31.4 GB/s
Maximum internal memory supported by processor	375 GB
Product type	Workstation
Motherboard chipset	-
Internal memory	4 GB
Memory channels	Quad-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Discrete graphics card model	AMD FirePro V4900
Maximum graphics card memory	1.024 GB
Graphics card family	AMD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Chassis type	Mini Tower
Product color	Black
Country of origin	China
Operating system installed	Windows 7 Ultimate
Sustainability certificates	ENERGY STAR
Processor code	SR0L9
Processor ARK ID	64600
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX

Weight and Dimensions

Depth	- mm
Weight	- g
