Connecting TV Source In 79
Connecting TV Source In
Typical TV Source Connections
These are only suggested configurations. Your system may be different.
Select the configuration that most closely matches your home system:
TV source type
Display/video
configuration Connector See:
Antenna From antenna TV Antenna In “Antenna” on page 80
Cable Cable directly from the wall
(without a cable TV set-top box
or digital cable receiver)
TV Antenna In “Cable Only” on page 81
One cable TV set-top box or
digital cable receiver
TV Source 1 In
Or
TV Antenna In
“One Cable TV Box or
Digital Cable Receiver” on
page 82
Two cable TV set-top boxes, or
digital cable receivers
TV Source 1 In
TV Source 2 In
“Two Cable TV Boxes, or
Two Digital Cable
Receivers” on page 84
Satellite One satellite receiver TV Source 1 In
Or
TV Antenna In
“One Satellite Receiver” on
page 86
Two satellite receivers TV Source 1 In
TV Source 2 In
“Two Satellite Receivers” on
page 88
Then see:
“Infrared Transmitter Connection” on page 90 (cable TV box, digital cable receiver, or satellite receiver only)
“Connecting Video Equipment” on page 95
