HP Z600 Specification

Cooling Above 1524m (5,000 ft) altitude, maximum operating temperature is de-rated
by 1°C (1.8°F) per 305m (1,000 ft) elevation increase
Physical Security and Serviceability
Access Panel Tool-less
Includes system board and memory information
Optical Drive Tool-less, no carrier or rails required
Floppy Drive Tool-less
Hard Drives Tool-less
Expansion Cards Tool-less
Processor Socket Yes
Green User Touch Points Yes, on tool-free internal chassis components
Color-coordinated Cables
and Connectors
Yes
Memory Tool-less
System Board Tool-less
Dual Color Power and HD
LED on Front of Computer
Yes
Configuration Record SW Yes
Over-Temp Warning on
Screen
Yes
Restore CD/DVD Set Restores the computer to its original factory shipping image - Can be obtained via HP Support
Dual Function Front
Power Switch
Also acts as a reset switch when held for 4 seconds
Padlock Support No
Cable Lock Support Yes, Kensington Cable Lock (optional): Prevents entire system theft only. 3mm x 7mm slot at rear of
system
Universal Chassis Clamp
Lock Support
No
Solenoid Lock and Hood
Sensor
Yes (optional)
Rear Port Control Cover Yes, locks rear IO cables to prevent cable theft
Serial, Parallel, USB,
Audio, Network,
Enable/Disable Port
Control
Enables or disables serial, parallel, USB, 1394, audio, and network ports
Removable Media
Write/Boot Control
User can prevent the workstation from writing to or booting from removable media
Power-On Password Prevents an unauthorized person from booting up the computer
Setup Password Prevents an unauthorized person from changing the system configuration
QuickSpecs
HP Z600 Workstation
System Technical Specifications
DA - 13277 North America — Version 51 — November 21, 2013 Page 25

HP Z600 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
Internal memory	1 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Maximum internal memory	24 GB
Memory layout (slots x size)	1 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
I/O ports	Front: 3 USB 2.0, 1 microphone in, 1 headphone out, optional 1 IEEE 1394a; Rear: 6 USB 2.0, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 1 RJ-45 to integrated Gigabit LAN, optional 1 serial; Internal: 3 USB 2.0
Serial ports quantity	0
USB 2.0 ports quantity	9
Power supply	650 W
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	2 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	2 PCI Express Gen2 x16, 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 2 PCI
Pointing device	HP USB Laser Scroll Mouse
Power requirements	650 watts wide-ranging, active Power Factor Correction, 85% efficient Power Supply
Storage drive type	250 GB 7200 rpm SATA NCQ SATA 250 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	600 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, optional SAS controller, LSI 3041E 4-port SAS/SATA, with RAID (0, 1 or 10) capability
Minimum storage drive space	146 GB
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Operating system installed	Windows Vista Business
Compatible operating systems	Red Hat Enterprise Linux WS 5 64-bit, Novell Suse SLED 11
Maximum graphics card memory	0.032 GB
Chassis type	Mini Tower
Country of origin	China
Processor code	SLBF9
Processor ARK ID	40711
Processor package size	42.5 x 45 mm

Weight and Dimensions

Depth	440 mm
Width	165.3 mm
Height	445.1 mm
Weight	19000 g
