HP Z600

LSI 3041E 4-Port SAS 3.0
Gb/s RAID Card
PCI Bus PCI-Express x4 lanes
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 1E and 10E
PCI Data Burst Transfer
Rate
250 MB/s per lane half duplex
500 MB/s per lane full duplex
1,000 MB/s 4-lane half duplex
SAS Bandwidth Half Duplex Single lane – 300 MB/s
Wide Port (2 lanes) – 600 MB/s
Wide Port (4 lanes) – 1200 MB/s
Full Duplex Single SAS Lane – 600 MB/s
Wide Port (2 lanes) –1200 MB/s
Wide Port (4 lanes) – 2400 MB/s
PCI Card Type 3.3 volt add-in card
PCI Voltage 12 V ± 10%
PCI Power 7.5 Watts
Bracket Full height and Low-profile
Certification Level PCI-Express 1.0a
IO Bus Four 3 Gb/s SAS/SATA ports
SAS Processor LSISAS1064E
Internal Connectors Four- SATA x1 connectors
External Connectors None
Maximum Number of SCSI
Devices
122
LED Indicators On-board activity and fault LEDs
Integrated Mirroring Integrated Mirroring option available
LSI 9212 4-Port SAS 6Gb/s
RAID Card
PCI Bus 8-lane, 5GT/s PCI Express 2.0
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 1E and 10
PCI Data Burst Transfer
Rate
Half Duplex, x4 PCIe 2000 MB/s
Full Duplex, x8 PCIe 4000 MB/s
SAS Bandwidth Half Duplex Single lane - 600 MB/s
Wide Port (2 lanes) - 1200 MB/s
Wide Port (4 lanes) - 2400 MB/s
Full Duplex Single SAS Lane - 1200 MB/s
Wide Port (2 lanes) -2400 MB/s
Wide Port (4 lanes) - 4800 MB/s
PCI Card Type 3.3V Add-in card
PCI Voltage 12 V ± 10%
PCI Power <13.5 Watts
Bracket Full height and Low-profile
QuickSpecs
HP Z600 Workstation
Technical Specifications - Hard Drive Controllers
DA - 13277 North America — Version 51 — November 21, 2013 Page 46
