System Configuration
Example Configuration #1
(ENERGY STAR QUALIFIED)
Processor Info
Memory Info
Graphics Info
Disks/Optical/Floppy
Power Supply
Other
1x Intel Xeon E5-2650 (Eight-Core)
4x 2GB DDR3 1600 (UDIMM)
1x NVIDIA Quadro 600
1x 250GB SATA 7200/1x 16X DVD-ROM SATA
800W 90% Custom PSU
1x NVIDIA Tesla C2075
Energy Consumption
115 VAC 230 VAC 100 VAC
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
Windows Idle (S0)
111 W 110 W 111 W
Windows Busy Typ (S0)
287 W 276 W 286 W
Windows Busy Max (S0)
396 W 390 W 398 W
Sleep (S3)
4.25 W 4.10 W 4.43 W 4.31 W 4.25 W 4.11 W
Off (S5)
1.81 W 1.62 W 2.07 W 1.89 W 1.79 W 1.61 W
Zero Power Mode (ErP)
0.25 W 0.45 W 0.23 W
Heat Dissipation
**
115 VAC 230 VAC 100 VAC
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
Windows Idle (S0)
379 btu/hr 375 btu/hr 379 btu/hr
Windows Busy Typ (S0)
979 btu/hr 942 btu/hr 976 btu/hr
Windows Busy Max (S0)
1351 btu/hr 1331 btu/hr 1358 btu/hr
Sleep (S3)
14.5 btu/hr 14.0 btu/hr 15.1 btu/hr 14.7 btu/hr 14.5 btu/hr 14.0 btu/hr
Off (S5)
6.18 btu/hr 5.53 btu/hr 7.06 btu/hr 6.45 btu/hr 6.11 btu/hr 5.49 btu/hr
Zero Power Mode (ErP)
0.85 btu/hr 1.54 btu/hr 0.78 btu/hr
Example Configuration #2
(ENERGY STAR QUALIFIED)
Processor Info
Memory Info
Graphics Info
Disks/Optical/Floppy
Power Supply
Other
1x Intel Xeon E5-2643 (Four-Core)
4x 4GB DDR3 1600 (UDIMM)
1x NVIDIA NVS 300
2x 500GB SATA 7200/1x 16X DVD-ROM SATA
800W 90% Custom PSU
-
Energy Consumption
115 VAC 230 VAC 100 VAC
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
Windows Idle (S0)
66.8 W 66.3 W 66.9 W
Windows Busy Typ (S0)
170 W 169 W 171 W
Windows Busy Max (S0)
193 W 190 W 193 W
Sleep (S3)
4.43 W 4.31 W 4.62 W 4.51 W 4.43 W 4.33 W
Off (S5)
1.81 W 1.38 W 2.07 W 1.64 W 1.78 W 1.36 W
Zero Power Mode (ErP)
0.24 W 0.45 W 0.23 W
Heat Dissipation
**
115 VAC 230 VAC 100 VAC
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
LAN Enabled
LAN Disabled
Windows Idle (S0)
228 btu/hr 226 btu/hr 228 btu/hr
Windows Busy Typ (S0)
580 btu/hr 577 btu/hr 583 btu/hr
Windows Busy Max (S0)
659 btu/hr 648 btu/hr 659 btu/hr
Sleep (S3)
15.1 btu/hr 14.7 btu/hr 15.8 btu/hr 15.4 btu/hr 15.1 btu/hr 14.8 btu/hr
Off (S5)
6.18 btu/hr 4.71 btu/hr 7.06 btu/hr 5.60 btu/hr 6.07 btu/hr 4.64 btu/hr
QuickSpecs
HP Z620 Workstation
System Technical Specifications
DA - 14262 North America — Version 35 — December 12, 2013
Page 25

Other manuals for HP Z620

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z620 and is the answer not in the manual?

HP Z620 Specifications

General IconGeneral
Tcase77.4 °C
Bus typeQPI
SteppingC2
FSB ParityNo
Processor cache15 MB
Processor cores6
Processor modelE5-2630
System bus rate7.2 GT/s
Processor seriesIntel Xeon E5-2600
Processor socketLGA 2011 (Socket R)
Processor threads12
Processor codenameSandy Bridge EP
Number of QPI links2
Processor frequency2.3 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency2.8 GHz
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurationsx4, x8, x16
Thermal Design Power (TDP)95 W
Number of processors installed1
CPU multiplier (bus/core ratio)28
Maximum number of PCI Express lanes40
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor800, 1066, 1333, 1600 MHz
Memory bandwidth supported by processor (max)42.6 GB/s
Maximum internal memory supported by processor750 GB
Audio system-
Product typeWorkstation
Motherboard chipsetIntel® C602
Internal memory4 GB
Memory channelsQuad-channel
Memory clock speed1600 MHz
Maximum internal memory- GB
Memory layout (slots x size)2 x 2 GB
HDD speed7200 RPM
HDD capacity500 GB
HDD interfaceSATA
Optical drive typeDVD Super Multi
Graphics cardFirePro V5900
External drive bays2 x 5.25\
Internal drive bays3 x 3.5\
Graphics card familyAMD
Serial ports quantity0
USB 2.0 ports quantity5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Chassis typeTower
Country of originChina
Operating system installedWindows 7 Professional
Power supply800 W
Maximum graphics card memory2.048 GB
Scalability2S
Processor ARK ID64593
Processor package size52.5 x 45.0 mm
Supported instruction setsAVX
Intel® Turbo Boost Technology1.0
Physical Address Extension (PAE)46 bit
Intel Secure Key Technology version1.00
Intel Identity Protection Technology version0.00
Weight and Dimensions IconWeight and Dimensions
Depth464.8 mm
Width171.5 mm
Height444.5 mm
Weight15500 g
