Environmental
Requirements
Temperature
Operating: 5°C to 35°C (40°F to 95°F)
Non-operating: -40°C to 60°C (-40°F to 140°F)
Humidity
Operating: 8% to 85% RH, non-condensing
Non-operating: 8% to 90% RH, non-condensing
Maximum Altitude
Operating: 3,048 m (10,000 ft)
Non-operating: 9,144 m (30,000 ft)
Dynamic (new)
Shock
Operating: ½-sine: 40 g, 2-3ms (~62 cm/sec)
Non-operating:
½-sine: 160 cm/s, 2-3ms (~105 g)
square: 20 g, 422 cm/s
NOTE:
Values represent individual shock events and do not indicate repetitive
shock events.
Vibration
Operating random: 0.5 g (rms), 5-300 Hz, up to 0.0025 g²/Hz
Non-operating random: 2.0 g (rms), 5-500 Hz, up to 0.0150 g²/Hz
NOTE:
Values do not indicate continuous vibration.
Cooling
Above 1524m (5,000 ft) altitude, maximum operating temperature is de-rated
by 1°C (1.8°F) per 305m (1,000 ft) elevation increase
Physical Security and Serviceability
Access Panel
Tool-less
Includes system board and memory information
Optical Drive
Tool-less, no carrier or rails required
Hard Drives
Tool-less
Integrated blind-mate drive carriers
Optional 5.25" external bay carriers
Expansion Cards
Tool-less
Processor Socket
1st socket on main system board. 2nd socket on optional 2nd CPU/Memory Module.
Green User Touch Points
Yes, on primary serviceable components
Color-coordinated Cables
and Connectors
Yes
Memory
Tool-less
System Board
Tool-less
2nd CPU/Memory Module: Tool-less
Dual Color Power and HD
LED on Front of Computer
Yes
Configuration Record SW
Yes
Over-Temp Warning on
Screen
Yes, at POST screen on reboot.
Restore CD/DVD Set
Yes, restores the computer to its original factory shipping image - Can be obtained via HP Support.
QuickSpecs
HP Z620 Workstation
System Technical Specifications
DA - 14262 North America — Version 35 — December 12, 2013
Page 28
