HP Z800 Specification

3.3V Aux Power LED on
System PCA
No
NIC LEDs (integrated)
(Green & Amber)
Yes
CPUs and Heatsinks A torx driver (T15) is needed to remove the CPU heatsink(s) before the CPU can be removed. CPU removal
is tool-less
Power Supply Diagnostic
LED
Yes
Front Power Button Yes
Front Power LED Yes, blue (normal), red (fault)
Front Hard Drive Activity
LED
Yes, green
Front ODD Activity LED Yes
Internal Speaker Yes
System/Emergency ROM
Flash Recovery
Recovers corrupted system BIOS.
Alert Standard Format
(ASF) Specification
Industry-standard specification for network alerting in operating system-absent environments
Cooling Solutions Air cooled forced convection, liquid cooling (optional)
Power Supply Fans 2x - 80mm x 25mm
CPU Heatsink Fan Mainstream (<=95W): 80mm x 15mm
Performance (>95W): 92mm x 15mm
MXM Heatsink Fan Rear: 2x - 92mm x 25mm
Front (850W config): 1x - 92mm x 25mm (upper position)
Front (1110W config): 2x - 92mm x 25mm
Memory Heatsink Fan 2x - 80mm x 25mm
HP Advanced System
Diagnostics Offline
Edition
HP Vision Diagnostics Offline Edition
The diagnostics utility must be booted from USB or CD, and enables you to perform testing and to view
critical computer hardware and software configuration information from various sources. This utility
enables you to:
Run diagnostics
View the hardware configuration of the system
Key features and benefits
HP Vision Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating the
hardware issues. In addition to robust management tools, service tools can be invaluable in quickly
resolving system problems. To streamline the service process and resolve problems quickly, it is
necessary to have the right information available at the time that a service call is placed. The primary
information requirement, which is also the one that provides the greatest insight into potential system
issues, is the configuration of the system. Vision Diagnostics helps provide higher system availability.
Typical uses of Vision Diagnostics are:
Testing and diagnosing apparent hardware failures
Documenting system configurations for upgrade planning, standardization, inventory tracking,
disaster recovery, and maintenance
QuickSpecs
HP Z800 Workstation
System Technical Specifications
DA - 13278 North America — Version 56 — November 21, 2013 Page 27

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
