Optional: LSI iBBU08 Battery Backup Unit for LSI

9260-8i

LA783AA

All RAID arrays must be less than 2 TB in size

NOTE 1:

Minimum of 2 hard drives needed. All hard drives must be identical (size/speed/type/bus/functional

capabilities). Must have 2, 3 or 4 HD Drives.

NOTE 2:

Minimum of 3 SATA hard drives needed. All hard drives must be identical

(size/speed/type/bus/functional capabilities).

At least 3 HD Drives required. May have 4th and 5th HD Drives. Drives must be the same drive

(size/speed/type/functional capability).

NOTE 3:

2 SATA or 2 SAS hard drives required. All hard drives must be identical

(size/speed/type/bus/functional capabilities).

Note 4: Minimum of 3 SATA hard drives needed. All SATA hard drives must be identical

(size/speed/type/bus/functional capabilities). Must have 3 or 4 HD Drives. 5 HD Drives not allowed.

SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,

provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please

visit:

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

for RAID

capabilities with Linux.

IS: Striping of 2 or more HDDs into a single logical volume

IM: Mirroring of 2 HDDs into a single logical volume

IME: Mirroring of 3 or more HDDs into a single logical volume

NOTE: Specific user-configured hardware SAS RAID configurations are supported on this Linux system. Please

visit:

http://www.hp.com/support/linux_hardware_matrix

for details

Graphics

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support Notes

Supported

Multi

Mixed

Professional 2D

NVIDIA Quadro NVS 295 256MB PCIe

Graphics

Y Y

FY943AA

NVIDIA NVS300 512MB PCIe Graphics

Y Y

XP612AA

AMD FirePro 2270 512MB Graphics

Y Y

LA524AA

3/1/2011

Entry 3D

NVIDIA Quadro 400 512MB Graphics

Y Y

LD542AA

NVIDIA Quadro 600 1GB Graphics

Y Y

WS093AA

NOTE 1

AMD FirePro V3900 1GB Graphics

Y Y

A6R69AA

AMD FirePro V4900 1GB Graphics

Y Y

A3J92AA

Mid-range

AMD FirePro V5900 2GB Graphics

Y Y

LS992AA

NVIDIA Quadro 2000 1GB Graphics

Y Y

WS094AA

High End 3D

NVIDIA Quadro 5000 2.5GB Graphics

Y Y

WS096AA

NVIDIA Quadro 4000 2GB Graphics

Y Y

WS095AA

NVIDIA Quadro 6000 6GB Graphics

Y Y

WS097AA

AMD FirePro V7900 2GB Graphics

Y Y

LS993AA

QuickSpecs

HP Z800 Workstation

Supported Components

DA - 13278 North America — Version 56 — November 21, 2013

Page 9
