HP Z800 Specification

Integrated LSI SAS 1068E
Controller with RAID 0, 1,
1E/10E
PCI Bus PCI-Express x8 lanes
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 1E/10E
PCI Data Burst Transfer
Rate
8 PCI-Express lanes at 2.5Gbps in each direction for a total bandwidth of
5.0Gbps for each full duplex lane. Total aggregate bandwidth of up to 4GBps
possible.
SAS Bandwidth Full Duplex LSI's SAS1068E 8-port SAS/SATA controller
supports 1.5 and 3.0Gb/s per port data transfer
rates.
PCI Card Type N/A
PCI Voltage N/A
PCI Power N/A
Bracket N/A
Certification Level PCI-Express 1.0a
IO Bus Eight 3Gbps SAS/SATA ports
SAS Processor LSISAS1068E
Internal Connectors Four- SATA x1 connectors
External Connectors None
Maximum Number of SCSI
Devices
32
LED Indicators On-board activity and fault LEDs
Integrated Mirroring Integrated Mirroring option available
LSI MegaRAID® 9260-8i
SAS 6Gb/s ROC RAID Card
and iBBU08 Battery
Backup Unit
PCI Bus PCI-Express (Gen2) V2.0 x8 lanes
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 5, and 6
RAID spans 10, 50 and 60
PCI Data Burst Transfer
Rate
Up to 4GB/s
PCI Card Type Low profile, single PCIe slot design with full height bracket.
The optional iBBU08 Battery Backup unit mounts on the controller card and
the assembly remains within a single PCIe slot width.
PCI Voltage +3.3V Add-in Card
PCI Power 12.5 Watts
Certification Level PCI-Express 2.0
IO Bus Eight 3 Gb/s and 6Gb/s compatible SAS/SATA ports
Internal Connectors Two SAS SFF8087 x4
External Connectors None
QuickSpecs
HP Z800 Workstation
Technical Specifications - Hard Drive Controllers
DA - 13278 North America — Version 56 — November 21, 2013 Page 48

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
