Page #32 background imageLoading...
Page #32 background image
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html
Additional Information
This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -
2002/95/EC.
This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
This product contains 0% recycled materials (by wt.)
Packaging
HP Workstation product packaging meets the following (refer to the HP General Specification for the
Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html
):
Does not contain restricted substances listed in HP Standard 011-1 General Specification for the
Environment (see link above).
Does not contain ozone-depleting substances (ODS).
Design packaging materials for ease of disassembly.
Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in excess of 100
ppm sum total for all heavy metals listed.
Maximizes the use of post-consumer recycled content materials in packaging materials.
All packaging material is recyclable.
Reduces size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
Packaging Materials
Internal
LDPE Foam: .592 kg
External
Cardboard carton and insert: 1.842 kg
Manageability
Industry Standard
Specifications
This product meets the following industry standard specifications for manageability functionality:
ASF 2.0 (via integrated Broadcom LAN)
Remote Manageability
Software Solutions
The HP Z800 Workstation is supported on the following remote manageability software consoles:
LANDesk Management Suite (PSG recommended solution)
Microsoft System Center Configuration Manager
HP Client Automation Enterprise
For questions or support for manageability needs, please visit:
http://www.hp.com/go/easydeploy
System Software Manager
For questions or support for SSM, please visit:
http://www.hp.com/go/ssm
Service, Support, and
Warranty
On-site Warranty and Service (
Note 1
): Three-years, limited warranty and service offering delivers on-site,
next business-day (
Note 2
) service for parts and labor and includes free telephone support (
Note 3
) 8am -
5pm. Global coverage (
Note 2
) ensures that any product purchased in one country and transferred to
another, non-restricted country will remain fully covered under the original warranty and service offering.
NOTE 1:
Terms and conditions may vary by country. Certain restrictions and exclusions apply.
NOTE 2:
On-site service may be provided pursuant to a service contract between HP and an authorized HP
third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
NOTE 3:
Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party
hardware and software. Toll-free calling and 24x7 support service may not be available in some countries.
QuickSpecs
HP Z800 Workstation
System Technical Specifications
DA - 13278 North America — Version 56 — November 21, 2013
Page 32

Other manuals for HP Z800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z800 and is the answer not in the manual?

HP Z800 Specifications

General IconGeneral
Processor cache8 MB
Processor modelE5560
Processor frequency2.8 GHz
Processor cache typeL2
Processor manufacturerIntel
Processor front side bus1333 MHz
Number of processors installed2
Audio systemIntegrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product typeWorkstation
Motherboard chipsetIntel® 5520
ECCYes
Maximum internal memory192 GB
HDD speed15000 RPM
HDD capacity446 GB
HDD interfaceSerial Attached SCSI (SAS)
Optical drive typeDVD Super Multi
Card reader integratedNo
I/O portsFront: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs1
USB 2.0 ports quantity9
Parallel ports quantity0
Power supply1110 W
Power consumption (typical)240 W
Non-operating altitude9100 m
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 90 %
Operating relative humidity (H-H)8 - 85 %
DisplayHP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays3 external 5.25\
Graphics card-
Keyboard typeHP PS/2 Standard Keyboard
Expansion slots1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing deviceHP USB Laser Scroll Mouse
Power requirements1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller typeSATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card featuresNo integrated Graphic Card
Maximum HDD capacity450 GB
Storage drive controllerIntegrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space146 GB
Operating system installedWindows Vista Business
Compatible operating systemsHP Installer Kit for Linux
Chassis typeMini Tower
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth526.5 mm
Width203.5 mm
Height445.1 mm
Weight19500 g
