Up to 5 SATA drives, 5 SAS, drives, or 6 SATA 2.5", Small Form Factor (SFF) drives

If 1st drive is SATA, 2nd drive can be EITHER SATA or SAS

3TB drive is not supported as a boot device.

3TB drives are ONLY supported in positions 2, 3, 4 and 5.

3TB drives must use LSI9260 Controller.

3TB drives are ONLY supported through HP specials and are not standard CTO devices.

SATA Solid State Drives

HP Solid State Drives for Workstations

HP 300GB SATA SSD

Y Y

LZ069AA

HP 160GB SATA SSD

Y Y

LZ704AA

HP 256GB SATA SSD

Y Y

A3D26AA

HP 128GB SATA SSD

Y Y

A3D25AA

Hard Drive Controllers

Factory

Configured

Option Kit

Part Number

Support

Notes

Factory integrated RAID on motherboard for SATA drives

RAID 0 Configuration - Striped Array

Y Y

See note 1

RAID 0 Data Configuration -- Boot/OS Drive + 2 Drive

Striped Array

Y Y

See note 2

RAID 1 Configuration - Mirrored Array

Y Y

See note 3

RAID 10 Configuration - Striped/Mirrored Array

Y Y

RAID 5 Configuration - Parity Array

Y Y

See note 4

Integrated SATA 3.0 Gb/s Controller

Y Y

Integrated LSI SAS 1068E Controller with RAID 0, 1, 1E/10E

Integrated LSI SAS 1068E Controller with RAID 0 (IS),

RAID 1(IM), RAID 10(IME) capability

Y Y

HP SAS Back Panel Connector kit

Y Y

Must have 4

or fewer SAS

hard drives to

configure this

option

HP SAS Back Panel Bulkhead Connector Kit

Y Y

HP SAS Back

Panel

Connector kit

required.

Internal SAS

HD drives are

not

supported

LSI MegaRAID® 9260-8i SAS 6Gb/s ROC RAID Card and iBBU08 Battery Backup Unit

LSI MegaRAID® 9260-8i SAS 6Gb/s ROC RAID Card

Y Y

WE465AA

QuickSpecs

HP Z800 Workstation

Supported Components

DA - 13278 North America — Version 56 — November 21, 2013

Page 8

Other manuals for HP Z800

Maintenance And Service Guide304 pages

Hardware Setup Guide54 pages

Configuration Guidelines24 pages

Questions and Answers:

Need help?

Do you have a question about the HP Z800 and is the answer not in the manual?

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China
