supported by Linux)
Protected by HP Services, including a 3 years parts, 3 years labor, and 3 years onsite service (3/3/3)
standard warranty. Terms and conditions vary by country. Certain restrictions and exclusions apply.
*Each processor supports up to 3 channels of DDR3 memory. To realize full performance at least 1 DIMM
must be inserted into each channel. To get full 6 channel support, 2 processors MUST be installed.
**SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,
provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please
visit
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf
for RAID
capabilities with Linux.
Form Factor
Rackable Minitower
Color
Black/Silver
I/O Slots
(see system
board section for more
details)
2 PCI Express Gen2 x16 slots (full-length, full-height)
2 PCI Express Gen2 x8 slots - with x16 connectors (full-length, full-height)
1 PCI Express Gen2 x4 slot - with x8 connector (half-length, full-height)
1 PCI Express Gen1 x4 slot - with x8 connector (full-length, full-height)
1 PCI 32bit/33MHz slot, (full-length, full-height)
1 Mechanical-only slot, supporting cards which mount only to the I/O bulkhead and not the
motherboard (half-length, full-height)
The PCIe x8 connectors are open ended, allowing a PCIe x16 card to be seated in the slot.
Bays
(see storage section
for more details)
Total Bays = 7
Internal Bays
4 internal 3.5" bays (4 with acoustic dampening rail assemblies)
External Bays
3 external 5.25" bays
Top bay device depth limit: 175mm
Middle bay device depth limit: 206mm
Bottom bay device depth limit: 206mm
Front I/O
3 USB 2.0, 1 Headphone Out, 1 Microphone In, and 1 IEEE 1394a
Rear I/O
1 IEEE-1394a
6 USB 2.0
1 Serial
PS/2 keyboard and mouse
2 RJ-45 to integrated Gigabit LAN
1 Audio Line In, 1 Audio Line Out, 1 Microphone In; audio ports can be retasked to function as line in, line
out, microphone, or headphone.
Internal USB
3 USB 2.0
3 USB 2.0 ports available by one 2x5 header and one 1x5 header: supports either up to two HP Internal USB
Port Kits, AMO- EM165AA, one on each header, or one USB Media Card Reader. Each Internal Port Kit has
two USB 2.0 connectors.
Chassis Dimensions
(H x W
x D)
44.4 x 20.3 x 52.5 cm; 17.5 x 8.0 x 20.7 inches
System Weight
Exact weights depend upon configuration
Minimum config – 19.5 kg (43 lb)
Typical config – 21 kg (46 lb)
Maximum config – 29 kg (64 lb)
Temperature
Operating:
5° to 35° C (40° to 95° F)
Non-operating
–40° to 60° C (–40° to 140° F)
QuickSpecs
HP Z800 Workstation
Overview
DA - 13278 North America — Version 56 — November 21, 2013
Page 4
