Item Component Spare part number
UHD, 400 nits, non-touch (includes cable) L17855-001
FHD, touch, privacy screen L17856-001
FHD, touch L17857-001
(3) Hinge cover
For use in models with touch displays L15538-001 (Hinge Kit)
For use in models with non-touch displays L15539-001 (Hinge Kit)
(4) Ambient light sensor board (includes double-sided tape) L15511-001
(5) Camera module
HD camera L15510-001
IR camera L15509-001
Microphone module (includes double-sided tape; not shown) L15512-001
(6) Camera cable (HD and IR models) L14370-001 (Cable Kit)
(7) Hinges (left and right) (for use in models with touch displays) L15538-001 (Hinge Kit)
Hinges (left and right) (for use in models with non-touch displays) L15539-001 (Hinge Kit)
(8) WLAN antenna (spared with display enclosure)
(9) WWAN antenna (spared with display enclosure)
(10) Display cable L14370-001 (Cable Kit)
(11) Display enclosure (includes tape, gasket, and foam for display)
For use in models without a WWAN module L17823-001
For use in models with a WWAN module L17824-001
Display assembly subcomponents 29
