19. If it is necessary to replace the WLAN antenna cables, peel the antennas from the top of the display
enclosure (1), remove the antenna cables from the routing path on the bottom of the display enclosure
(2), and then remove the antenna cables (3).
NOTE: The WLAN antennas are available with the display enclosure.
20. If it is necessary to replace the WWAN antenna cables, peel the antennas from the top of the display
enclosure (1), remove the antenna cables from the bottom and sides of the display enclosure (2), and
then remove the antenna cables (3).
NOTE: The WWAN antennas are available with the display enclosure.
The display enclosure is available as spare part number L63376-001.
Reverse this procedure to reassemble and install the display assembly.
76 Chapter 6 Removal and replacement procedures for authorized service provider parts
