HP ZBook 15u G5

To Next Page

To Previous Page

Cable Kit

Item Description Spare part number

Cable Kit, includes: L14361-001

(1) Keyboard cable

(2) USB board cable

(3) Card reader cable

(4) TouchPad cable

(5) Fingerprint reader cable

(6) NFC cable

Cable Kit 29
