HP ZBook 17 Specification

DP 1.2 redrive: DisplayPort monitors capable of supporting DP 1.2 may be directly attached to the Thunderbolt port to
achieve HBR2 and MST functionality.
DP display with miniDP connector may be attached directly to TB (Thunderbolt) port.
DP display with standard DP connector and other legacy displays (HDMI, DVI, VGA) may be attached to TB with the use of a
dongle.
DP1.2 MST feature ("daisy-chain" feature) is supported through TB port.
* Thunderbolt is new technology. Install all the latest drivers for your Thunderbolt device before connecting the device to the
Thunderbolt port. Thunderbolt cable and Thunderbolt device (sold separately) must be compatible with Windows. To determine
whether your device is Thunderbolt Certified for Windows, see https://thunderbolttechnology.net/products .
DisplayPort w/MST (Multi-stream Transport)
Supports resolutions up to Supports resolutions up to QFHD 3840 x 2160, 24/30-bit color depth at 60 Hz, and WUXGA (1920 x
1200) monitors, 24/30-bit color depth at 120 Hz.
DisplayPort Feature
Multi-stream Transport (MST): Multi-stream Transport is a DP 1.2 feature that allows daisy chaining of DP 1.2 monitors
(requires built in support of DP 1.2 MST in monitor), or the use of DP 1.2 hubs with MST to achieve 4 active displays without
a docking station.
Optimal configurations for enabling the maximum number of displays (up to five independent displays when using an HP
Advanced Docking station (sold separately) with hybrid graphics enabled):
With Port Replicator:
Dock DP + Dock DVI + Internal Display + Thunderbolt DP port (enabling VGA will drop one digital display)
With Advanced Port Replicator:
Dock DP1 + Dock DP2 + Internal Display + Thunderbolt DP port (enabling VGA will drop one digital display)
VGA
Port supports resolutions up to 2048 x 1536 at 75 Hz, and lower resolutions at up to 100 Hz
DVI-D (single link)
Video signal available through DVI port in optional HP Docking Station (sold separately) as well as through DP to DVI adapters to
use without the optional HP Docking Station
supports resolutions up to 1600 x 1200 at both full and reduced blanking, and 1920 x 1200 at reduced blanking
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
FLASH CACHE MODULE
Optional mSATA Flash cache module support for Intel Smart Response Technology. (Available only with standard non-SED hard
drive. Cannot be combined with any Solid State Drive)
QuickSpecs
HP ZBook 17 Mobile Workstation
Features
DA - 14723 Worldwide — Version 9 — December 12, 2013 Page 7

HP ZBook 17 Specifications

General

Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Mobile series
Processor socket	PGA946
Processor threads	8
Processor codename	Haswell
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	47 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	DTS Studio Sound HD
Product type	Mobile workstation
Motherboard chipset	Intel® QM87
Password protection	Yes
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Memory layout (slots x size)	2 x 4 GB
Form factor	Clamshell
Pointing device	Touchpad
Battery life (max)	- h
Disc types supported	CD, DVD
Headphone connectivity	3.5 mm
eSATA/USB 2.0 ports quantity	0
HDD capacity	0 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Optical drive type	DVD-ROM
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display surface	Matt
Display diagonal	17.3 \
Native aspect ratio	16:9
Display number of colors	16.78 million colors
On-board graphics card ID	0x416
Discrete graphics card model	NVIDIA® Quadro® K3100M
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card memory	1.7 GB
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
WWAN	Not installed
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Microphone in	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Product color	Black
Country of origin	China
Processor code	SR15H
Processor ARK ID	75117
Intel TSX-NI version	0.00
Processor package size	37.5 x 32 x 1.6 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	75 Wh
AC adapter power	200 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	5.27 A
AC adapter output voltage	19 V
Operating altitude	0 - 3050 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	272 mm
Width	416 mm
Height	34 mm
Weight	3480 g
