Villa Series Installation
Stainless steel flange Hearth Oven
Preparation
Preparation
Before beginning installation or operation of the product, please make sure all the parts are present. If
any part is damaged or missing, do not attempt to assemble, install or operate this product.
Please have a licensed hearth installer perform the installation
Always have two to three people to install the oven
The Villa Series installed weighs approx. 400lbs. Please make sure the counter cutout has
support on each side where the oven will be installed, otherwise the weight from the oven and
heat might break the counter.(please follow weight requirement from the cut-out diagram)
How to assemble The Villa Series
l
1. Once the opening to your counter is made place the
stainless steel flange in the opening and lock in tabs to
secure flange in opening.(tighten screws)
