HPC PENTA24EI - Selecting the Location; Clearances Around Fire Pit

3
4/28/2017 860-EI
IMPORTANT: High / Low Models- if pressure is low, this will reduce flame height on HIGH setting, possibly
resulting in little to no flame variation.
• If not using supplied flex line, ensure any flex line that may be used from the permanent main fuel supply to
the product is rated to the stated max BTU of the product and certified to ANSI Z21.75*CSA 6.27.
• The EI Series is not for use with small LP Tanks and must utilize permanent fixed piping for fuel supply.
ELECTRICAL Key Points:
• Verify correct 110VAC- 1 amp or 24VAC- 4 amp power supply. All electronic applications should utilize a
GFCI protected circuit.
• IMPORTANT: 24VAC powered fire pit inserts:
A Class II 24VAC, 4 amp, 100W transformer must be used to power the fire pit and able to be switched
on and off from a remote location to allow for easy access or emergency.
24VAC Wire Sizing: Wire Lengths 75ft or less: 14 gauge
Wire Lengths 76ft or more: 12 gauge
3. Selecting the Location
x All fire pit inserts and systems are designed and intended for outdoor use only.
x Pick a location that allows sufficient horizontal room and safe egress to enjoy the fire pit while allowing
a safe distance from the heat and flame.
x IMPORTANT: Deck Installation- If installing fire pit on a wood or composite deck it is required to use
the Deck Insulation Kit(s) and locally bought paver stones. Kit includes basalt material and instructions.
#FPI-DECK39SQ; #FPI-DECK20SQ. Also refer to drawing- Deck Insulation Kit- Install.
x Select a location where the fire pit can be attended during operation. Never leave an operating fire pit
unattended or by someone not familiar with its operation or emergency shut off locations.
Young children should be carefully supervised when they are in the area of fire pit.
x There must be an electrical shut off (wall switch or breaker) on the exterior of the fire pit or on adjacent
wall to allow for emergency shutdown and maintenance.
x Fire pits create very high temperatures - Combustibles must be located far enough away that there is no
risk of ignition.
x Select a location with good drainage and allows easy access for installation and maintenance of the fire
pit.
CLEARANCES AROUND FIRE PIT:
Fire Pit Clearances
Up to 200k BTU
201k ~ 400k BTU
Under valve box when applicable for drainage
2”
2”
Sides surrounding fire pit from structure or combustibles
36”
48”
Overhead clearance above product
84”
Non-combustible screen only.
For more information please refer to Clearance Drawings- see the last two pages.
