9
4/28/2017 860-EI
EI FIRE PIT START UP
1. STOP! Read the safety information on “What to Do If Smell Gas” (Pg. 1).
2. Confirm there is no debris in the fire pit (as mentioned in warnings) including water.
3. Turn “ON” electrical power and gas to fire pit.
4. Using wall switch or remote to turn “ON” fire pit - this may take several cycles to purge any air.
5. To reset after lockout, power unit down, wait 5 minutes, then restart.
6. Once the fire pit has ignited DO NOT leave unattended.
This product is not for use with small tanks. It is intended to be connected to fixed piping systems only.
7. Fire Pit Operation
x Before use, be sure to test all gas connections for leaks. Do not use fire pit if there is any evidence of leaking
gas. If leaking gas suspected, turn off the main gas supply and repair immediately.
x Both children and adults should be alerted to the hazards of high surface temperatures and should stay away to
avoid burns and clothing ignition.
x Do not use the enclosure as a seating area. Wind and gusty conditions will affect the flame in an unpredictable
manner. Please turn the fire pit OFF if condition exist that is not safe for patrons.
x Do not use fire pit if any part has been submerged under water. Immediately call a qualified service technician
to inspect the fire pit.
x Solid fuels shall not be burned in the fire pit. Leaves, sticks, wood, paper, clothing, food material, should be
kept away from the fire pit. Fire pit is not for cooking. Make sure that there is no vegetation or other objects
over the top or sides of the fire pit that could interfere with safe operation. See clearances in Section 3-
Selecting the Location.
x If lava rock is wet, allow fire pit to burn for 45 minutes prior to coming within 15 feet of the fire pit.
x When fire pit is not in operation turn off power via wall switch or breaker.
x When not in use the fire pit must be covered at all times.
Start Up:
Initial Start-up: Several “on/off” cycles may be necessary to purge air in gas lines after system installation.
Fire pit will lockout after 15 attempts to light pilot: Please power OFF then ON to restart.
Sequence of Operation:
1. The igniter will be powered (glow red) for 5 seconds before pilot valve opens.
2. The igniter will only be powered the initial 15 seconds of the 30 second pilot cycle. This sequence will repeat
up to 15 times (~15 minutes) before going into lockout. To reset, turn “OFF” power then back “ON” again.
3. Pilot flame will ignite and warm thermocouple- it may take 30 seconds at times for thermocouple to get hot. If
thermocouple is not hot in 60 seconds, system will shut down then go back to Step 1.
4. Once thermocouple is hot, main valve will open allowing main burner to ignite.
5. If pilot flame is blown out at any time, system will shut down, and then automatically restart (Step 1).
• The following sections explain operation of:
A. On / Off Models B. High / Low Models- Remote Control C. High / Low Models- Smartphone Control
A. ON / OFF MODELS- Please operate as follows.
