PUNCH MACHINE
™
Note maximum range of possible adjustment.
Any further adjustment MUST be done by
authorized factory personnel.
Fig. 7.2.3
After the recalibration of the needle is done,
retighten the Adjustment Screw.
Fig. 7.2.4
No. 1200PCH
