7 Cabling examples
The following basic cabling examples are included:
• “Large Form Factor D36x0 disk enclosures — maximum capacity configuration” (page 44)
• “Small Form Factor D37x0 disk enclosures — maximum capacity configuration” (page 45)
• “Dual domain example — best fault tolerance cabling” (page 46)
• “Dual domain — best performance cabling” (page 47)
• “Dual domain—alternative cabling” (page 48)=
IMPORTANT: The following illustrations demonstrate connecting disk enclosures to a generic
host. Cabling restrictions may exist for server connect and controller enclosure connect
environments. For more information, see the user documents for your controller or controller
enclosure.
43
