Item Description Function
3 Activity LED Indicates which appliance module is active:
• O—Indicates that the appliance module is the standby in a Highly Available
configuration or HPE OneView is in an error state.
• Solid green—Indicates that the appliance module is active.
• Flashing green—Indicates that the reset button has been pressed and held for more
than 10 seconds, which initiates a reimaging of the appliance module. The active
LED does not continue to flash green during the reimaging process.
4 Power LED Indicates power to the appliance module:
• O—No power. Verify that the appliance module is fully inserted into the frame.
• Flashing amber— appliance module is initializing.
• Solid amber— appliance module is powered o.
• Solid green— appliance module is powered on.
5 Reset button Using an applicator such as a paper clip, press the recessed button to reset the
appliance module:
• Press and release—Resets the appliance module.
• Press and hold until activity LED is flashing green—Initiates reimaging of the
appliance module from files on the USB flash drive plugged into the appliance
module.
6 USB port USB 20 port for connecting a USB drive to flash a USB recovery image.
Component and LED identification 44
