Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
-50- HD09 Series User Manual V1.1
Terminal detection (F19.23)
Ref. Code Function Description Setting Range [Default]
F19.23 Electric instant terminal detection 0,1 [0]
0: Rising edge effective.
• Suitable for use after power-on, in the absence of human intervention and does not allow automatic
operation, to prevent damage to equipment and protect personal safety.
• These situations need to be started when the inverter is powered on and the run command is
completed.
1: Electrical level.
• Suitable for ensured equipment and personal safety, in order to improve the automation and efficiency
of equipment, the need for the inverter to run immediately on power.
• In these cases, the drive will operate immediately as long as the command is given to the terminal,
regardless of whether the run command is given before the inverter is powered up or after power-up.
Braking function (F19.24)
Ref. Code Function Description Setting Range [Default]
F19.24 Action voltage of brake unit 630 - 750V [Type confirmed]
Note: It is valid only when the inverter is running.
Frequency adjustment range (F19.37)
Ref. Code Function Description Setting Range [Default]
F19.37 Frequency adjustment range 000 - 101 [100]
Bits: The main frequency calculation
• 0: 0 to Max.
• 1: Minus to Max.
Ten: Reserved
Hundred: Synthesis of frequency calculation
• 0: 0 to Max.
• 1: Minus to Max.
Short detection (F19.38)
Ref. Code
Function Description Setting Range [Default]
F19.38 Phase short circuit detection action selection 0,1 [1]
Used to select whether or not to detect a short circuit between each run.
0: No detection.
1: Detection.
