hpmont HD09-4T2P2G User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 9 MODBUS Communication Protocol
HD09 Series User Manual V1.1 -69-
6. Slave 2 deceleration stop command
Request
frame
Address Code Register address Register content Checksum
0x02 0x06 0x32 0x00 0x10 0x04 0x8B 0x42
Response
frame
Address Code Register address Register content Checksum
0x02 0x06 0x32 0x00 0x10 0x04 0x8B 0x42
7. Slave 2 fault reset
Request
frame
Address Code Register address Register content Checksum
0x02 0x06 0x32 0x00 0x11 0x00 0x8B 0x11
Response
frame
Address Code Register address Register content Checksum
0x02 0x06 0x32 0x00 0x11 0x00 0x8B 0x11
8. Read from the salve 2 inverter output current (such as: Inverter output current of 12.5A), register
contents0x00,0x7D
Request
frame
Address Code Register address Read bytes Checksum
0x02 0x03 0x33 0x15 0x00 0x01 0x9A 0xB9
Response
frame
Address Code Response bytes Register content Checksum
0x02 0x03 0x02 0x00 0x7D 0x3C 0x65
9. Read the output frequency of slave 2 (such as: Inverter output frequency of 50.00Hz), register
contents0x13,0x88
Request
frame
Address Code Register address Read bytes Checksum
0x02 0x03 0x33 0x10 0x00 0x01 0x64 0x38
Response
frame
Address Code Response bytes Register content Checksum
0x02 0x03 0x02 0x13 0x88 0xF1 0x12
10. Read the slave bus 2 bus voltage (state parameter), the response should be 537V
Request
frame
Address Code Register address Read bytes Checksum
0x02 0x03 0x33 0x19 0x00 0x01 0x5A 0xBA
Response
frame
Address Code Response bytes Register content Checksum
0x02 0x03 0x02 0x02 0x19 0x3C 0xEE
