Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―160― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F13.51 Reserved
F13.52 Reserved
Group F14 Reserved (refer to pages 88
89)
Group F15 Digital I/O Terminal Parameters (refer to pages 89
102)
F15.00
DI1 terminal function
selection
0: Reserved
1: Inverter enabled
2: FWD function
3: REV function
4: Three-wire operation
mode
5,6,7: Frequency source
selection 1, 2, 3
8: AI to be the frequency
source
9,10: Run command source
selection 1,2
11: Terminal control mode to
be the run command source
12: External stop command
input
13－16: Multi-step frequency
terminal 1－4
17: Frequency ramp (UP)
18: Frequency ramp (DN)
19: Clearing auxiliary
frequency setting
20,21: Forward and reverse
jog 1 command control input
(JOGF1/ JOGR1)
22,23: Forward and reverse
jog 2 command control input
(JOGF2/ JOGR2)
24: Jog 1 command control
input
25: Jog 1 direction control
input (Remark: When select
20 and 21, the functions 24
and 25 are invalid)
26: Acc./Dec. time selection
terminals 1
27: Acc./Dec. time selection
2 1 ×
F15.01
DI2 terminal function
selection
3 1 ×
F15.02
DI3 terminal function
selection
0 1 ×
F15.03
DI4 terminal function
selection
0 1 ×
