Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －161－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F15.04
DI5 terminal function
selection
terminals 2
28: Acc./Dec. mode selection
29: Acc./Dec. prohibition
30: Switch to ordinary
running mode
31: Reset the stop status of
PLC operation
32: Pausing the process PID
33: Disabling the process
PID
34: Holding PID integral
35: Clearing PID integral
36: Switch to wobble
operation
37: Reset the wobble
operating status
38: DC braking start while
stopping
39: External pause signal
(normally-open input)
40: External pause signal
(normally-closed input)
41: Coast to stop
(normally-open input)
42: Coast to stop
(normally-closed input)
43: Emergency stop
44: External fault signal
(normally-open input)
45: External fault signal
(normally-closed input)
46: External reset (RST)
input
47: Switch between motor 1
and motor 2
48: Timing function input
49: Clearing the length
50: Clearing the counter to
zero
51: Counter’s triggering
signal input
52: Length counting input
(only DI6 terminal is enabled)
53: Pulse frequency input
(only DI6 terminal is enabled)
54－84: Reserved
85: Pausing PLC operation
86: Terminal stop DC braking
0 1 ×
F15.05
DI6 terminal function
selection
0 1 ×
F15.06
DI7 terminal (option
terminal) function
selection
0 1 ×
F15.07
DI8 terminal (option
terminal) function
selection
0 1 ×
F15.08
DI9 terminal (option
terminal) function
selection
0 1 ×
A
