Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―162― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F15.09 Reserved
F15.10 Reserved
F15.11 Reserved
F15.12
Acc./Dec. rate of
UP/DN terminal
0.00－99.99Hz/s 1.00Hz/s
0.01Hz
/s
×
F15.13
Terminal detecting
interval
0: 2ms
1: 4ms
2: 8ms
0 1 ○
F15.14
Terminal detecting filter
number
0－10000 2 1 ○
F15.15
Terminal input positive
and negative logic
setting
Bit0－Bit8 is corresponding
to DI1－DI9
Bitx: DIy terminal input
positive and negative logic
0: Positive logic
1: Negative logic
Only when using HD30-EIO
and HD30-WIO will DI7－DI9
be enabled.
000 1 ○
F15.16
FWD/REV operation
mode
0: Two-wire operation mode
1
1: Two-wire operation mode
2
2: Three-wire operation
mode 1
3: Three-wire operation
mode 2
0 1 ×
F15.17
Terminal operating
selection due to fault of
external equipment
0: Coast to stop
1: Emergency stop
2: Decelerate to stop
3: Continue to run
0 1 ×
F15.18
DO1 terminal function
selection
0: Reserved
1: Inverter ready
2: Inverter is running (RUN)
3: Inverter is forward running
4: Inverter is reverse running
5: Inverter is DC braking
6: Inverter is in
zero-frequency status
2 1 ×
