Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual -163-
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F15.19
DO2 terminal function
selection
7: Inverter is in
zero-frequency running
8: Reserved
9,10: Frequency detection
threshold (FDT1,FDT2)
11: Frequency arriving signal
(FAR)
12: Limitation of upper limit of
frequency
13: Limitation of lower limit of
frequency
14: Limitation of upper/lower
limits of wobble frequency
15: Simple PLC operating
status indication
16: Simple PLC pausing
indication
17: Simple PLC cycle
completion indication
18: Completion of simple
PLC operation stages
19: Completion of simple
PLC operation
20: Output data from SCI
communication
21: Preset operating time out
22: Timing function output
23: Preset counting value
reach
24: Indicating counting value
reach
25: Setting length arrive
26: Indication of motor 1 and
motor 2
27,28: Reserved
29: Undervoltage lock-up
signal (LU)
30: Overload signal (OL)
31: Inverter fault
32: External fault
33: Inverter auto-reset fault
34: Three-phase power
supply forward input
35-37:Reserved
38: High-frequency output
(only DO2)
0 1 ×
F15.20
RLY1 relay function
selection
31 1 ×
F15.21
RLY2 relay (extension
relay) function
selection
0 1 ×
F15.22
RLY3 relay (extension
relay) function
selection
0 1 ×
F15.23
RLY4 relay (extension
relay) function
selection
0 1 ×
F15.24
Output terminal
positive and negative
Bit0-Bit2 is corresponding
to DO1-DO2
000 1 ○
A
