Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―164― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
logic selection Bit2－Bit5 is corresponding
to RLY1－RLY4
Bitx: DOy and RLYy
terminals output positive and
negative logic
0 means positive logic
1 means negative logic
Only when using HD30-EIO
will RLY2－RLY4 be
enabled.
F15.25
ON side delay time of
timing function
0.00－300.00s 0.00s 0.01s ○
F15.26
OFF side delay time of
timing function
0.00－300.00s 0.00s 0.01s ○
F15.27 FAR range 0.00－100.00Hz 2.50Hz 0.01Hz ○
F15.28
Zero-frequency
operation threshold
0.00－upper limit 0.00Hz 0.01Hz ○
F15.29
Zero-frequency
hysteresis
0.00－upper limit 0.00Hz 0.01Hz ○
F15.30 FDT1 detection mode
0: Detect according to the
reference frequency
1: Detect according to the
output frequency
0 1 ○
F15.31 FDT1 level 0.00－upper limit 50.00Hz 0.01Hz ○
F15.32 FDT1 lag 0.00－upper limit 1.00Hz 0.01Hz ○
F15.33 FDT2 detection mode
0: Detect according to the
reference frequency
1: Detect according to the
output frequency
0 1 ○
F15.34 FDT2 level 0.00－F00.06 50.00Hz 0.01Hz ○
F15.35 FDT2 lag 0.00－F00.06 1.00Hz 0.01Hz ○
F15.36 Preset operating time
0－65535h
0: Preset operating time is
disabled
0h 1h ○
F15.37
Preset counting value
arriving
F15.38－9999 0 1 ○
F15.38
Specified counting
value arriving
0－F15.37 0 1 ○
F15.39 Reserved
F15.40 Reserved
F15.41 Reserved
F15.42 Reserved
F15.43 Terminal output delay 0.0－100.0s 0.0s 0.1s ×
Group F16 Analogue I/O Terminal Parameters (refer to pages 102
－
106)
