hpmont HD30-4T015G/018P User Manual

Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －165－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F16.00
Display panel with
potentiometer function
selection
0: Reserved
1: Upper limit frequency
setting source
2: Frequency setting source
3: Auxiliary frequency
reference
4: Process PID reference
5: Process PID feedback
6: Process PID regulating
upper limit
7: Process PID regulating
lower limit
8: Motor overheating signal
input
0 1 ×
F16.01
Analogue input AI1
function selection
2 1 ×
F16.02
Analogue input AI2
function selection
5 1 ×
F16.03
Analogue input AI3
function selection
0 1 ×
F16.04
Analogue input AI4
function selection
0 1 ×
F16.05
Analogue input AI1
bias
-100.0－100.0% 0.0% 0.1% ○
F16.08
Analogue input AI2
bias
-100.0－100.0% 0.0% 0.1% ○
F16.11
Analogue input AI3
bias
-100.0－100.0% 0.0% 0.1% ○
F16.14
Analogue input AI4
bias
-100.0－100.0% 0.0% 0.1% ○
F16.06
Analogue input AI1
gain
-10.00－10.00 1.00 0.01 ○
F16.09
Analogue input AI2
gain
-10.00－10.00 1.00 0.01 ○
F16.12
Analogue input AI3
gain
-10.00－10.00 1.00 0.01 ○
F16.15
Analogue input AI4
gain
-10.00－10.00 1.00 0.01 ○
F16.07
Analogue input AI1
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.10
Analogue input AI2
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.13
Analogue input AI3
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.16
Analogue input AI4
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.17
Maximum input pulse
frequency
0.0－50.0kHz 10.0kHz 0.1kHz ○
F16.18
Input pulse filtering
time
0－500ms 10ms 1ms ○
